Clutch Band Servo Accumulator
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 315-B03-01 | Clutch Band Servo Accumulator | 1993 - ... |
ENGINE: VG30E
SPEED: F4
TRANSMISSION: AT
|
No illustration for this section
The full parts list is available below
Parts in this diagram 14
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0092250400 | 0092250400 | RING - SNAP | |||
| 3137251X01 | 31372M | RETAINER - ACCUMULATOR | |||
| 3152641X02 | 31672N | SEAL - O RING, ACCUMULATOR | |||
| 3152641X03 | 31673N | SEAL - O RING, ACCUMULATOR | |||
| 3160541X02 | 31674Q | SPRING - ACCUMULATOR SERVO | |||
| 3160541X06 | 31674 | SPRING - ACCUMULATOR SERVO | |||
| 3160541X09 | 31674N | SPRING - ACCUMULATOR SERVO | |||
| 3160541X10 | 31674M | SPRING - ACCUMULATOR SERVO | |||
| 3167221X00 | 31672M | SEAL - O RING, ACCUMULATOR | |||
| 3167321X00 | 31673M | SEAL - O RING, ACCUMULATOR |
of
2
