Camshaft Valve Mechanism
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 130-D01-01 | Camshaft Valve Mechanism | 1983 - ... |
ENGINE: LD20
|
No illustration for this section
The full parts list is available below
Parts in this diagram 33
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 080340551A | 080340551A | BOLT - HEX | |||
| 089151461A | 089151461A | WASHER - SPRING | |||
| 1301205E00 | 13024A | BOLT - SPROCKET, CAMSHAFT | |||
| 1302405E00 | 13024 | SPROCKET - CAMSHAFT | |||
| 1303205E00 | 13001A | PIN - DOWEL | |||
| 1307005E00 | 13070M | TENSIONER ASSY - BELT | |||
| 1307105E00 | 13070H | SPRING - TENSIONER | |||
| 1307405E00 | 13170M | PULLEY ASSY - IDLER | |||
| 1320105E00 | 13201 | VALVE - INTAKE | |||
| 1320223E00 | 13202 | VALVE - EXHAUST |
