Transfer Case
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 331A-001-01 | Transfer Case | 2010 - ... |
DRIVE: 4WD
ENGINE: MR20DE
|
No illustration for this section
The full parts list is available below
Parts in this diagram 12
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 089315121A | 089315121A | PLUG - TAPER | |||
| 11026EN10A | 33100Q | GASKET - FILLER PLUG | |||
| 31098EN10B | 33102Q | HOSE - BREATHER | |||
| 31377EN11A | 33120A | BOLT | |||
| 321034N21A | 33100H | PLUG - FILLER | |||
| 32105C6901 | 33102D | PIN - DOWEL | |||
| 32106EN10A | 33102DA | PIN - DOWEL | |||
| 33101JG20A | 33102S | CASE SET - TRANSFER | |||
| 33111EN100 | 33111 | SEAL - OIL, RING GEAR | |||
| 381894N200 | 38189X | SEAL - OIL, DRIVE PINION |
of
2
