| Code | Name | Period | Specifications |
|---|---|---|---|
| 462A-001-03 | Brake Piping Control Piping | 2024 - ... |
BODY: HB
|
| Part Number | Offers | Part Code | Name | Match |
|---|---|---|---|---|
| 01125N6041 | 46020AA | BOLT | ||
| 01125N8021 | 46020A | BOLT | ||
| 462062J00A | 46201B | SPRING - LOCK, BRAKE HOSE | ||
| 462063DA0A | 46201B | SPRING - LOCK, BRAKE HOSE | ||
| 462104CL0A | 46201M | HOSE ASSY - BRAKE, FRONT | ||
| 462104CL0B | 46201MA | HOSE ASSY - BRAKE, FRONT | ||
| 46237A4600 | 46201D | GASKET - BRAKE HOSE | ||
| 462404CL0A | 46240 | TUBE ASSY - BRAKE, FRONT RH | ||
| 462424CL0A | 46242 | TUBE ASSY - BRAKE, FRONT LH | ||
| 462504CL0A | 46250 | TUBE ASSY - BRAKE, MASTER CYLINDER TO FRONT | ||
| 462524CL0A | 46252M | TUBE ASSY - BRAKE, MASTER CYLINDER TO REAR | ||
| 462612DX0A | 46261 | BRACKET - BRAKE TUBE | ||
| 462614CL1A | 46261+A | BRACKET - BRAKE TUBE | ||
| 462712DR0A | 46020J | CLIP | ||
| 462714BA0A | 46020JA | CLIP | ||
| 46271JE20A | 46020JB | CLIP | ||
| 462724CL0A | 46020JD | CLIP | ||
| 46272JE20A | 46020JC | CLIP | ||
| 462824CL0A | 46282 | TUBE ASSY - BRAKE, REAR | ||
| 462834CL0A | 46283 | TUBE ASSY - BRAKE, REAR | ||
| 46313JG00A | 46313 | CONNECTOR - BRAKE TUBE | ||
| 463560E00A | 46201C | BOLT - UNION, FRONT BRAKE HOSE |
