| Code | Name | Period | Specifications |
|---|---|---|---|
| 270A-002-01 | Heater Blower Unit Brower Unit | 2015 - 2019 |
BODY: HB
ENGINE: HRA2DDT
|
| Part Number | Offers | Part Code | Name | Match |
|---|---|---|---|---|
| 0124100011 | 27020B | NUT | ||
| 271114BU1A | 27020DC | SCREW | ||
| 27138DF30A | 27020J | CLAMP | ||
| 27138DFA0A | 27020J | CLAMP | ||
| 271394EM0A | 27139B | ROD - FOOT TO MODE | ||
| 27139DFA0A | 27139B | ROD - FOOT TO MODE | ||
| 27140DF30A | 27115 | CORE ASSY - FRONT HEATER | ||
| 27140DFA0A | 27115 | CORE ASSY - FRONT HEATER | ||
| 271431KB0A | 27143N | HEATER ASSY - PTC | ||
| 271554EM0A | 27155P | LINK - MAIN | ||
| 27155DFA0A | 27155P | LINK - MAIN | ||
| 271594EM0A | 27159M | LINK - FOOT | ||
| 27159DFA0A | 27159M | LINK - FOOT | ||
| 27165DF30A | 27165U | LEVER - VENTILATOR | ||
| 27165DFA0A | 27165U | LEVER - VENTILATOR | ||
| 271684EM0A | 27168U | LEVER - FOOT | ||
| 27168DFA0A | 27168U | LEVER - FOOT | ||
| 27174DF30A | 27157 | PACKING | ||
| 27174DFA0A | 27157 | PACKING | ||
| 271754EM0A | 27175M | BRACKET - FRONT HEATER | ||
| 27175DF30A | 27175M | BRACKET - FRONT HEATER | ||
| 27175DFA0A | 27175M | BRACKET - FRONT HEATER | ||
| 271992J000 | 27020DD | SCREW | ||
| 27199DFA0A | 27020DD | SCREW | ||
| 27226DF30A | 27226 | MOTOR ASSY - BLOWER | ||
| 27226DFA0A | 27226 | MOTOR ASSY - BLOWER | ||
| 272294M40A | 27040A | BOLT | ||
| 27277DF31A | 27274L | AIR FILTER KIT - AIR CONDITIONER | ||
| 27277DFA0A | 27274L | AIR FILTER KIT - AIR CONDITIONER | ||
| 27277DFA0B | 27274L | AIR FILTER KIT - AIR CONDITIONER | ||
| 27280DF30A | 27280 | EVAPORATOR ASSY - FRONT | ||
| 27280DFA0A | 27280 | EVAPORATOR ASSY - FRONT | ||
| 27289DF30A | 27020C | GROMMET | ||
| 27289DFA0A | 27020C | GROMMET | ||
| 272B2DF30A | 272B2 | COVER - FILTER, RH | ||
| 27385DF30A | 27385M | CASE ASSY - BLOWER, REAR | ||
| 275264EM0A | 27526R | LEVER - MODE CONTROL | ||
| 27526DFA0A | 27526R | LEVER - MODE CONTROL | ||
| 277234BU0A | 27723X | SENSOR - EVAPORATOR | ||
| 277494BU0A | 27749 | STEPPER - MOTOR | ||
| 27749DFA0A | 27749 | STEPPER - MOTOR | ||
| 27749DFA1A | 27749 | STEPPER - MOTOR | ||
| 277614BA0A | 27761Q | MODULE ASSY - POWER | ||
| 27761DFA0A | 27761Q | MODULE ASSY - POWER | ||
| 27761DFA0B | 27761Q | MODULE ASSY - POWER | ||
| 277814EM0A | 27781P | ROD | ||
| 277814EM1A | 27781PA | ROD | ||
| 27781DFA0A | 27781PA | ROD | ||
| 27781DFA1A | 27781P | ROD | ||
| 924774GF0A | 92476 | SEAL - O RING | ||
| 924774GF1A | 92476+A | SEAL - O RING | ||
| 92477DFA0A | 92476 | SEAL - O RING | ||
| 92477DFA1A | 92476+A | SEAL - O RING |
