Cylinder Block Oil Pan Intermediate Housing
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 110R-003-01 | Cylinder Block Oil Pan Intermediate Housing | 2014 - 2017 |
ENGINE: R9M
|
No illustration for this section
The full parts list is available below
Parts in this diagram 10
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0112500Q0D | 11110FA | BOLT | |||
| 1102600Q0H | 11128A | WASHER - DRAIN PLUG | |||
| 1111000Q3D | 11110+A | PAN ASSY - OIL | |||
| 1111000Q3F | 11110+A | PAN ASSY - OIL | |||
| 1112800Q0A | 11128 | PLUG - DRAIN | |||
| 1114000Q2L | 11140 | GAUGE - OIL LEVEL | |||
| 1114500Q1F | 11145 | SENSOR ASSY - OIL LEVEL | |||
| 1115100Q1C | 15146 | GUIDE - OIL LEVEL GAUGE | |||
| 1506600Q0D | 11012G | SEAL - O RING | |||
| 1514600Q0G | 15146 | GUIDE - OIL LEVEL GAUGE |
