| Code | Name | Period | Specifications |
|---|---|---|---|
| 211A-001-01 | Water Hose Piping | 2009 - 2011 |
ENGINE: ZD30DDTI
|
Parts in this diagram 23
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0112508164 | 14053B | BOLT | |||
| 0155800154 | 14055BB | CLAMP - HOSE | |||
| 0155800421 | 14055B | CLAMP - HOSE | |||
| 089183081A | 089183081A | NUT - FLANGE, HEX | |||
| 140532DB0A | 14053 | PIPE - WATER INLET MANIFOLD | |||
| 140532DB0B | 21040M | TUBE ASSY - WATER | |||
| 14055MA70B | 14055+B | HOSE - WATER | |||
| 14055MA70C | 14055+A | HOSE - WATER | |||
| 140560W800 | 14056 | HOSE - WATER | |||
| 14056MA70C | 14056+A | HOSE - WATER |
