Engine Control Vacuum Piping
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 223A-001-01 | Engine Control Vacuum Piping | 2001 - 2003 |
ENGINE: KA24DE
|
No illustration for this section
The full parts list is available below
Parts in this diagram 14
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 081208121E | 081208121E | BOLT - HEX | |||
| 14912VJ210 | 14912NB | TUBE - ANTI EVAPORATION CONTROL | |||
| 14912VW620 | 14912NC | TUBE - ANTI EVAPORATION CONTROL | |||
| 14918VJ200 | 14960E | CONNECTOR, A | |||
| 14932VW001 | 14957U | BRACKET - VALVE | |||
| 14932VW002 | 14957U | BRACKET - VALVE | |||
| 14950VW600 | 14950 | EVAPORATIVE EMISSION CANISTER | |||
| 14950VW60A | 14950 | EVAPORATIVE EMISSION CANISTER | |||
| 16439N2100 | 14962 | CLAMP - HOSE, B | |||
| 18961VJ200 | 22320J | HOSE - VACUUM CONTROL |
of
2
