Transmission Case Clutch Release Ttransmission Case Clutch Release
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 321B-002-01 | Transmission Case Clutch Release Ttransmission Case Clutch Release | 2024 - 2024 |
ENGINE: YD25DDTI
TRANSMISSION: 6MT
|
Parts in this diagram 32
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0812061633 | 0812061633 | BOLT - HEX | |||
| 110264N200 | 32103A | GASKET - DRAIN PLUG | |||
| 11058H1001 | 30537C | WASHER - BALL PIN | |||
| 305015X00A | 30501 | SLEEVE - CLUTCH RELEASE | |||
| 3050269F1A | 30502 | BEARING - CLUTCH RELEASE | |||
| 30514CD000 | 30514 | SPRING - HOLDER, CLUTCH RELEASE BEARING | |||
| 305314KV0B | 30531 | LEVER - WITHDRAWAL, CLUTCH | |||
| 3053466300 | 30534 | SPRING - RETAINING, WITHDRAWAL LEVER | |||
| 30537CD000 | 30537 | PIN - BALL, WITHDRAWAL LEVER | |||
| 30542EB30A | 30542 | DUST COVER - WITHDRAWAL LEVER |
