Transmission Gear Main Gear
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 322B-002-01 | Transmission Gear Main Gear | 2012 - 2012 |
AREA: GCC
DRIVE: 4WD
TRANSMISSION: MT
|
Parts in this diagram 15
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 322000F095 | 32200S | GEAR SET - MAIN & COUNTER DRIVE | |||
| 3220332G00 | 32203+A | BEARING - MAIN DRIVE | |||
| 3224131G0A | 32241 | SHAFT - MAIN | |||
| 3224280S60 | 32230 | GEAR ASSY - 1ST, MAIN SHAFT | |||
| 3225080G14 | 32250 | GEAR ASSY - 2ND, MAIN SHAFT | |||
| 3226070L74 | 32260 | GEAR ASSY - 3RD, MAIN SHAFT | |||
| 3226401G0A | 32264R | BEARING - NEEDLE, MAIN SHAFT | |||
| 3260058S91 | 32610Q | SLEEVE & HUB - COUPLING | |||
| 3260370L00 | 32602 | SPRING - SHIFTING INSERT | |||
| 3260470L15 | 32604+C | RING - BAULK |
