Windshield Wiper Windshield Wiper
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 288A-002-01 | Windshield Wiper Windshield Wiper | 2011 - 2012 |
BODY: SC
|
No illustration for this section
The full parts list is available below
Parts in this diagram 20
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0143600431 | 28810A | SCREW | |||
| 083636162G | 083636162G | SCREW - MACHINE | |||
| 089111062G | 089111062G | NUT - HEX | |||
| 089113081A | 089113081A | NUT - HEX | |||
| 089152381A | 089152381A | WASHER - SPRING | |||
| 28810VN10A | 28810 | MOTOR ASSY - WINDSHIELD WIPER | |||
| 28810VN20A | 28810 | MOTOR ASSY - WINDSHIELD WIPER | |||
| 28820VN10A | 28835 | BRACKET ASSY - WIPER MOTOR | |||
| 2882865F00 | 28828 | SEAL - BALL RETAINER | |||
| 2882865F01 | 28828+A | SEAL - BALL RETAINER |
