Throttle Chamber
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 163A-003-01 | Throttle Chamber | 2010 - 2011 |
ENGINE: KA24DE
|
No illustration for this section
The full parts list is available below
Parts in this diagram 6
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 16119F4010 | 16298M | CHAMBER ASSY - THROTTLE | |||
| 1612240P0A | 16292M | BOLT - CHAMBER | |||
| 1612273C00 | 16292MA | BOLT - CHAMBER | |||
| 161753S500 | 16293 | GASKET - THROTTLE CHAMBER | |||
| 16175VJ200 | 16293 | GASKET - THROTTLE CHAMBER | |||
| 24079VJ200 | 24041Y | SUB HARNESS |
