Engine Transmission Mounting
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 112A-001-01 | Engine Transmission Mounting | 2008 - 2009 |
ENGINE: KA24DE
|
No illustration for this section
The full parts list is available below
Parts in this diagram 14
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0122500062 | 11510B | NUT | |||
| 0122500072 | 11520B | NUT | |||
| 0122500082 | 11510B | NUT | |||
| 081210201E | 081210201E | BOLT - HEX | |||
| 081270201E | 081270201E | BOLT - HEX | |||
| 11210VJ20A | 11220 | INSULATOR - ENGINE MOUNTING, FRONT | |||
| 11232F4000 | 11232 | BRACKET - ENGINE MOUNTING, RH | |||
| 11233F4000 | 11233 | BRACKET - ENGINE MOUNTING, LH | |||
| 11284VJ21A | 11235 | HEAT SHIELD PLATE | |||
| 11298VJ20A | 11520A | BOLT |
of
2
