Power Steering Gear
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 492B-001-01 | Power Steering Gear | 2009 - ... |
AXLE RATIO: 4WD/LNG
ENGINE: KA24
|
Parts in this diagram 7
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 49200VK91B | 49200 | GEAR ASSY - POWER STEERING | |||
| 4932155G26 | 49202S | SEAL KIT - OIL, SECTOR SHAFT | |||
| 493452S725 | 49203K | SEAL KIT - PINION, POWER STEERING GEAR | |||
| 4936955G01 | 49369 | CAP - REAR COVER | |||
| 4937155G00 | 49371 | COVER ASSY - SECTOR | |||
| 4937555G0A | 49371A | BOLT - SECTOR COVER | |||
| 4951455G0A | 49353 | NUT - SELF LOCK |
