Instrument Meter Gauge Front View
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 248A-001-01 | Instrument Meter Gauge Front View | 1994 - 1999 |
BODY: S
ENGINE: GA13DS
|
No illustration for this section
The full parts list is available below
Parts in this diagram 37
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 0145100581 | 25010A | BOLT | |||
| 0854041610 | 0854041610 | SCREW - TAPPING | |||
| 2481188Y00 | 25031M | HOUSING - COMBINATION METER, LOWER | |||
| 2481189Y00 | 25031M | HOUSING - COMBINATION METER, LOWER | |||
| 2481285Y00 | 25031 | HOUSING - COMBINATION METER, UPPER | |||
| 2481286Y02 | 25031 | HOUSING - COMBINATION METER, UPPER | |||
| 2481389Y00 | 24813 | COVER - FRONT, COMBINATION METER | |||
| 248142M174 | 25030 | PLATE ASSY - PRINTED CIRCUIT | |||
| 248143M681 | 25030 | PLATE ASSY - PRINTED CIRCUIT | |||
| 2481492Y01 | 25030 | PLATE ASSY - PRINTED CIRCUIT |
