Engine Control Vacuum Piping
Search by VIN to filter parts for your vehicle
Part name must be at least 2 characters.
| Code | Name | Period | Specifications |
|---|---|---|---|
| 223E-001-03 | Engine Control Vacuum Piping | 1998 - ... |
ENGINE: GA16DE
|
No illustration for this section
The full parts list is available below
Parts in this diagram 17
| Part Number | Offers | Part Code | Name | Compatibility | Match |
|---|---|---|---|---|---|
| 2247216E00 | 22472J | CLAMP - HIGH TENSION CABLE | |||
| 0812061210 | 0812061210 | BOLT - HEX | |||
| 0891110637 | 0891110637 | NUT - HEX | |||
| 0891533610 | 0891533610 | WASHER - SPRING | |||
| 147452M100 | 14957M | BRACKET - SOLENOID VALVE | |||
| 1474573C01 | 14957M | BRACKET - SOLENOID VALVE | |||
| 1495065Y10 | 14950 | EVAPORATIVE EMISSION CANISTER | |||
| 1495631U00 | 14956V | SOLENOID VALVE ASSY | |||
| 1495631U10 | 14956V | SOLENOID VALVE ASSY | |||
| 16439N2100 | 14911E | CLAMP - HOSE |
of
2
